2 swivel castors and 2 fixed castors

Industrial applications. They are easily manoeuvrable for medium loads over long distances. Maximum Load Capacity = Total Load/3

4 fixed castors central pivoting

For medium- heavy loads. Good straight travelling and relatively easy manoeuvrability. The two central fixed castors are used to pivot on when manoeuvring. Castors can be replaced by wheels on a central axle. Maximum Load Capacity = Total Load/2.

2 swivel castors and 2 fixed castors in the centre

Good load capacity and manoeuvrability in small spaces. Fixed castors can be replaced by a one wheel set. Maximum Load Capacity = Total Load/2

4 swivel castors

Good load capacity and excellent manoeuvrability in all directions. Not for use over long distances or uneven surfaces. Maximum Load Capacity = Total Load/2

1 swivel castor and 2 fixed castors

For use with light loads for manoeuvrable trolleys. Weight should be evenly distributed on a small appliance. Maximum Load Capacity =Total Load/3.

4 swivel castors and 2 fixed castors in the centre

Ideal for large trolleys and heavy loads.Trolleys should have a strong base and will turn on the centre castors. Maximum Load Capacity = Total Load/2.

3 swivel castors

First-rate manoeuvrability. Recommended for drums and barrels and light trolleys. Maximum Load Capacity = Total Load/3.
