Which castors do you need?

SERIE ZLI INOX-UT

Categories

Polypropylene castors with stainless steel (AISI 304) components. Especially indicated to support high-loads up to 120 Kg.

It is used in: outdoor areas, food trolleys, canteens, dining rooms, restaurants, food industry, conveyor belts, light machinery for the construction, poultry farms, slaughterhouses, meat industry, dairy industry and chemical industry.

Suitable for mechanical engineering projects by draftsmen and project executors.

UT: undeformable and very resistant. Easy to start and move.

See comparative

ZLI SERIES-UT

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Hole diameter Overall height Offset
2-3077 80 100 34 Bearing: Plain 95x80 80x60 8 108 71
2-3078 100 110 36 Bearing: Plain 95x80 80x60 8 127 80
2-3079 125 120 36 Bearing: Plain 95x80 80x60 8 155 88
2-5153 125 300 45 Bearing: Plain 128x106 105x80 11 165 113

ZLI SERIES-UT

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Hole diameter Overall height Offset
2-3080 80 100 36 Bearing: Plain 100x80 80x60 8 108 --
2-3081 100 110 36 Bearing: Plain 100x80 80x60 8 127 --
2-3082 125 120 36 Bearing: Plain 100x80 80x60 8 155 --
2-5155 125 300 45 Bearing: Plain 133X107 105x80 11 165 --

ZLI SERIES-UT

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Hole diameter Overall height Offset
2-3083 80 100 34 Bearing: Plain 95x80 80x60 8 108 71
2-3084 100 110 34 Bearing: Plain 95x80 80x60 8 127 80
2-3085 125 120 35 Bearing: Plain 95x80 80x60 8 155 88
2-5154 125 300 45 Bearing: Plain 128x106 105x80 11 165 113

ZLI SERIES-UT

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Through hole diameter Overall height Offset
2-3086 80 100 34 Bearing: Plain -- -- 12 108 71
2-3087 100 110 36 Bearing: Plain -- -- 12 127 80
2-3088 125 120 35 Bearing: Plain -- -- 12 155 88

ZLI SERIES-UT

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Through hole diameter Overall height Offset
2-3089 80 100 34 Bearing: Plain -- -- 12 108 71
2-3090 100 110 36 Bearing: Plain -- -- 12 127 80
2-3091 125 120 36 Bearing: Plain -- -- 12 155 88

Other castors SERIE ZLI INOX

SERIE ZLI INOX-POL
SERIE ZLI INOX-POL
Diametro 80-125 mm
Carga 100-300 kg
