Which castors do you need?

SERIE ZVI INOX-PGA

Categories

Black rubber castors with stainless steel (AISI 304) components. Especially indicated to support high-loads up to 135 Kg.

It is used in: outdoor areas, food trolleys, canteens, dining rooms, restaurants, food industry, logistics for military missions material, packaging machines, conveyor belts, stainless steel constructions, light machinery for the construction, containers, roll containers and transport cages.

Suitable for mechanical engineering projects by draftsmen and project executors.

PGA: smooth and noiseless castor. Does not leave marks on floor.

See comparative

ZVI SERIES-PGA

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Hole diameter Overall height Offset
2-1327 60 40 22 Bearing: Plain 70x55 55x42 8 84 59
2-1319 80 80 32 Bearing: Plain 105x80 86/80x60 8 110 77
2-1724 100 110 32 Bearing: Plain 105x80 86/80x60 8 131 91
2-1182 100 110 32 Bearing: Plain 106x86 86/80x60 8 133 94
2-4928 125 135 32 Bearing: Plain 105x80 86/80x60 8 158 104
2-1184 125 135 32 Bearing: Plain 106x86 86/80x60 8 155 107

ZVI SERIES-PGA

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Hole diameter Overall height Offset
2-1328 60 40 22 Bearing: Plain 57x52 42x26 8 84 --
2-1320 80 80 32 Bearing: Plain 107x86 80x60 8 110 --
2-1725 100 110 32 Bearing: Plain 107x86 80x60 8 131 --
2-1183 100 110 32 Bearing: Plain 107x86 80x60 8 133 --
2-4929 125 135 32 Bearing: Plain 107x86 80x60 8 158 --
2-1185 125 135 32 Bearing: Plain 107x86 80x60 8 155 --

ZVI SERIES-PGA

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Hole diameter Overall height Offset
2-2348 80 80 32 Bearing: Plain 105x80 86/80x60 8 110 77
2-1835 100 110 32 Bearing: Plain 105x80 86/80x60 8 131 91
2-1662 100 110 32 Bearing: Plain 106x86 86/80x60 8 133 94
2-4930 125 135 32 Bearing: Plain 105x80 86/80x60 8 158 104
2-1663 125 135 32 Bearing: Plain 106x86 86/80x60 8 155 107

ZVI SERIES-PGA

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Through hole diameter Overall height Offset
2-1404 80 80 32 Bearing: Plain -- -- 10 104 77
2-4138 80 80 32 Bearing: Plain -- -- 12 104 77
2-1830 100 110 32 Bearing: Plain -- -- 10 125 91
2-4139 100 110 32 Bearing: Plain -- -- 12 124 91
2-1405 100 110 32 Bearing: Plain -- -- 12 128 94
2-4931 125 135 32 Bearing: Plain -- -- 12 151 104
2-1406 125 135 32 Bearing: Plain -- -- 12 151 107

ZVI SERIES-PGA

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Through hole diameter Overall height Offset
2-2353 80 80 32 Bearing: Plain -- -- 10 104 77
2-4140 80 80 32 Bearing: Plain -- -- 12 104 77
2-1836 100 110 32 Bearing: Plain -- -- 10 125 91
2-4141 100 110 32 Bearing: Plain -- -- 12 124 91
2-1666 100 110 32 Bearing: Plain -- -- 12 128 94
2-4932 125 135 32 Bearing: Plain -- -- 12 151 104
2-1667 125 135 32 Bearing: Plain -- -- 12 151 107

Other castors SERIE ZVI INOX

SERIE ZVI INOX-PS
SERIE ZVI INOX-PS
Diametro 80-200 mm
Carga 75-215 kg
SERIE ZVI INOX-PS Grey
SERIE ZVI INOX-PS Grey
Diametro 160-200 mm
Carga 160-215 kg
SERIE ZVI INOX-PGZ
SERIE ZVI INOX-PGZ
Diametro 80-200 mm
Carga 80-180 kg
SERIE ZVI INOX-UT
SERIE ZVI INOX-UT
Diametro 60-200 mm
Carga 60-500 kg
SERIE ZVI INOX-TN
SERIE ZVI INOX-TN
Novedad
Diametro 80-80 mm
Carga 250-250 kg
SERIE ZVI-INOX FT
SERIE ZVI-INOX FT
Diametro 80-200 mm
Carga 200-600 kg
SERIE ZVI INOX-PO
SERIE ZVI INOX-PO
Ampliamos Gamma
Diametro 80-200 mm
Carga 150-600 kg
SERIE ZVI INOX-POL
SERIE ZVI INOX-POL
Diametro 60-200 mm
Carga 70-400 kg
SERIE ZVI INOX-POA
SERIE ZVI INOX-POA
Diametro 80-200 mm
Carga 120-300 kg
SERIE ZVI INOX-TD
SERIE ZVI INOX-TD
Diametro 80-200 mm
Carga 200-600 kg
SERIE ZVI INOX-TT
SERIE ZVI INOX-TT
Diametro 80-100 mm
Carga 100-125 kg
SERIE ZVI INOX-THG
SERIE ZVI INOX-THG
Diametro 100-100 mm
Carga 100-100 kg
