SERIE BH-PGI

Categories

Injected grey rubber castors. Especially indicated to support loads up to 70 Kg.

It is used in: supermarkets, display stands, furniture, stackable boxes, stools, display cabinets, clothes racks, catering carts, hospital equipment, clinical furniture and drips.

PGI: does not scratch or leave marks on floor. Noiseless.

See comparative

BH SERIES-PGI

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Hole diameter Overall height Offset
1-0163 60 40 22 Bearing: Plain 70x55 54x38 6 88 62
1-0180 80 60 24 Bearing: Plain 70x55 54x38 6 112 77
3-0004 100 70 25 Bearing: Plain 70x55 54x38 6 134 90

BH SERIES-PGI

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Hole diameter Overall height Offset
2-4337 60 40 22 Bearing: Plain 75x66 54x38 6 88 --
2-2459 80 60 24 Bearing: Plain 75x66 54x38 6 112 --
2-2460 100 70 25 Bearing: Plain 75x66 54x38 6 134 --

BH SERIES-PGI

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Hole diameter Overall height Offset
2-4480 60 40 22 Bearing: Plain 70x55 54x38 6 88 62
1-0386 80 60 24 Bearing: Plain 70x55 54x38 6 112 77
1-0302 100 70 25 Bearing: Plain 70x55 54x38 6 134 90

BH SERIES-PGI

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Through hole diameter Overall height Offset
1-0170 60 40 22 Bearing: Plain -- -- 10 85 62
1-0179 80 60 24 Bearing: Plain -- -- 10 108 77
3-0008 100 70 25 Bearing: Plain -- -- 10 130 90

BH SERIES-PGI

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Through hole diameter Overall height Offset
2-4481 60 40 22 Bearing: Plain -- -- 10 85 62
1-0387 80 60 24 Bearing: Plain -- -- 10 108 77
1-0303 100 70 25 Bearing: Plain -- -- 10 130 90

BH SERIES-PGI

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Hole diameter Overall height Offset
1-0176 60 40 22 Bearing: Plain 40x40 -- -- 87 62
1-0294 80 50 24 Bearing: Plain 40x40 -- -- 108 77

BH SERIES-PGI

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Hole diameter Overall height Offset
2-4635 60 40 22 Bearing: Plain 40x40 -- -- 87 62
1-0388 80 50 24 Bearing: Plain 40x40 -- -- 108 77

BH SERIES-PGI

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Stem dimensions Overall height Offset
2-1489 60 40 22 Bearing: Plain -- -- 12x30 85 62
2-1491 80 50 24 Bearing: Plain -- -- 12x30 108 77

BH SERIES-PGI

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Stem dimensions Overall height Offset
2-4636 60 40 22 Bearing: Plain -- -- 12x30 85 62
2-1492 80 50 24 Bearing: Plain -- -- 12x30 108 77
