Which castors do you need?

SERIE ZVR-FT

Categories

Reinforced nylon castors, especially indicated to support high-loads up to 700 Kg.

It is used in: internal logistics tools, repair shops, tool trolleys, mobile platforms, transport tools, elevating platforms, food industry, transport carts, logistics for military missions material.

Mainly used in the industrial sector, aeronautic sector, automobile factories and food industry.

Suitable for mechanical engineering projects by draftsmen and project executors.

FT: castors especially indicated for food and chemical industry applications. Does not leave marks on floor. Reinforced. High resistance to impacts and collisions.

See comparative

ZVR SERIES-FT

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Hole diameter Overall height Offset
2-3873 150 650 45 Bearing: Plain 140x110 105x80 10 198 132
2-3881 150 650 45 Bearing: Ball 140x110 105x80 10 198 132
2-3877 200 700 50 Bearing: Plain 140x110 105x80 10 244 160
2-3885 200 700 50 Bearing: Ball 140x110 105x80 10 244 160
2-0089 250 700 57 Bearing: Plain 140x110 105x80 10 297 185
2-0092 250 700 57 Bearing: Ball 140x110 105x80 10 297 185

ZVR SERIES-FT

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Hole diameter Overall height Offset
2-3874 150 650 45 Bearing: Plain 136x116 105x80 10 198 --
2-3882 150 650 45 Bearing: Ball 136x116 105x80 10 198 --
2-3878 200 700 50 Bearing: Plain 136x116 105x80 10 244 --
2-3886 200 700 50 Bearing: Ball 136x116 105x80 10 244 --
2-0090 250 700 57 Bearing: Plain 136x116 105x80 10 297 --
2-0093 250 700 57 Bearing: Ball 136x116 105x80 10 297 --

ZVR SERIES-FT

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Hole diameter Overall height Offset
2-3875 150 650 45 Bearing: Plain 140x110 105x80 10 198 132
2-3883 150 650 45 Bearing: Ball 140x110 105x80 10 198 132
2-3879 200 700 50 Bearing: Plain 140x110 105x80 10 244 160
2-3887 200 700 50 Bearing: Ball 140x110 105x80 10 244 160
2-0091 250 700 57 Bearing: Plain 140x110 105x80 10 297 185
2-0094 250 700 57 Bearing: Ball 140x110 105x80 10 297 185

ZVR SERIES-FT

Code Diameter Load Width of tyre Bearing Plate dimensions Distance between holes Hole diameter Overall height Offset
2-3876 150 650 45 Bearing: Plain 140x110 105x80 10 198 132
2-3884 150 650 45 Bearing: Ball 140x110 105x80 10 198 132
2-3880 200 700 50 Bearing: Plain 140x110 105x80 10 244 160
2-3888 200 700 50 Bearing: Ball 140x110 105x80 10 244 160
2-0416 250 700 57 Bearing: Plain 140x110 105x80 10 297 185
2-0417 250 700 57 Bearing: Ball 140x110 105x80 10 297 185

Other castors SERIE ZVR

SERIE ZVR-HU
SERIE ZVR-HU
Ampliamos Gamma
Diametro 150-250 mm
Carga 650-700 kg
SERIE ZVR-HUAB
SERIE ZVR-HUAB
Diametro 150-200 mm
Carga 600-700 kg
SERIE ZVR-AUB
SERIE ZVR-AUB
Ampliamos Gamma
Diametro 160-250 mm
Carga 600-700 kg
SERIE ZVR-AUGB
SERIE ZVR-AUGB
Diametro 160-200 mm
Carga 550-700 kg
SERIE ZVR-TA
SERIE ZVR-TA
Diametro 150-200 mm
Carga 650-700 kg
SERIE ZVR-AUAB
SERIE ZVR-AUAB
Diametro 160-200 mm
Carga 550-700 kg
SERIE ZVR-AUSB
SERIE ZVR-AUSB
Diametro 160-200 mm
Carga 500-650 kg
SERIE ZVR-DE
SERIE ZVR-DE
Novedad
Diametro 160-250 mm
Carga 350-500 kg
SERIE ZVR-DEGB
SERIE ZVR-DEGB
Ampliamos Gamma
Diametro 160-250 mm
Carga 350-500 kg
SERIE ZVR-AUAGB
SERIE ZVR-AUAGB
Diametro 160-200 mm
Carga 500-650 kg
